MONDRAKER CRAFTY CARBON XR LTD 2023



MONDRAKER CRAFTY CARBON XR LTD 2023 / CARBON / OHLINS TTX AIR / OHLINS RXF 38 / SRAM X01 EAGLE 12v / SRAM CODE RSC / MAVIC E-DEEMAX / MAXXIS / BOSCH PERFORMANCE LINE CX RACE / 23,2 Kg

More details

Availability:

Immediate store stock or supplier. Please contact us to find out our best commercial conditions: 05 16 83 64 41 or 06 30 32 02 25

Sale!-21%

9 499,00 € tax incl.

Recommended retail price : 11 999,00 € tax incl.

Color
Frame Size :
GROUPE DE TRANSMISSION
Collection
Batterie
Freinage

More info

  • ico-cuadro.svg

    Frame

    Crafty Stealth Air full Carbon, e-Bike Optimized Zero Suspension System, 150mm travel, Forward Geometry, internal non-removable battery, Boost 12x148mm rear axle, tapered head tube, one-piece Monoblock upper link, HHG internal cable routing, MAX capacity sealed bearings, oversize 17mm axles, integrated dropout speed sensor, exclusive plastic motor covers.

    ico-tallas.svg

    Sizes

    S: 380mm / M: 420mm / L: 450mm / XL: 490mm

    ico-amortiguador.svg

    Rear shock

    Öhlins TTX Air 205X65mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload. Trunnion top mount, 25x10mm bottom bushings

    ico-amortiguador.svg

    Shock settings

    C20 compression, R35 rebound. Volume reducers 12.000 (2xF+1D)

    ico-horquilla.svg

    Fork

    Öhlins RXF 38 M.2 29, 170mm, TTX18 Twin Tube cartridge, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: high speed compression lever with climb mode, low-speed compression, rebound, air preload, ramp chamber

    ico-direccion.svg

    Headset

    Acros custom for 1-1/2" head tube, angular contact bearings 40x52x7, Internal cable routing

    ico-potencia.svg

    Stem

    Onoff Krypton FG 30mm, CNC, 31.8mm barbore

    ico-manillar.svg

    Handlebar

    Onoff Krypton Carbon 1.0, rise: 25mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

    ico-punyos.svg

    Grips

    Onoff Desert, 1lock-on, 135mm

    ico-tija.svg

    Seatpost

    Onoff Pija dropper internal, diameter 31.6mm, S size: 405x95-125mm, M size 458x120-150mm, L size: 498x140-170mm, XL size: 498x140-170mm

    ico-sillin.svg

    Saddle

    FIZIK Terra Aidon X5 145mm

    ico-freno-delantero.svg

    Front brake

    Sram Code RSC, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

    ico-freno-trasero.svg

    Rear brake

    Sram Code RSC, oversized 4-piston caliper, Centerline 200mm IS 6 bolts one-piece rotor, steel-backed metal sintered pads

    ico-manetas.svg

    Brake lever

    Sram Code RSC, SwingLink and lever pivot bearings, tools-free reach and contact point adjust

    ico-llantas.svg

    Rims

    Mavic E-Deemax S 29, 30mm internal width, Maxtal welded, PFP, tubeless, 28 spokes

    ico-radios.svg

    Spokes

    Mavic straight-pull double butted, contactless lacing

  • ico-buje-trasero.svg

    Front hub

    Mavic, Boost 15x110mm, IS 6 bolts

    ico-buje-trasero.svg

    Rear hub

    Mavic, Boost 12x148mm, ID360 Ratchet system, IS 6 bolts, XD freehub

    ico-neumatico.svg

    Front tire

    Maxxis Minion DHF 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

    ico-neumatico.svg

    Rear tire

    Maxxis Minion DHR II 29x2.6, tubeless ready, 3C MAXX TERRA, EXO+ Protection, 120TPI, folding bead

    ico-bielas.svg

    Crankset

    E.13 TRS Race carbon ebike, 165mm

    ico-bielas.svg

    Rings

    Sram X-Sync 2 Eagle 34T, steel, narrow-wide, 104 BCD

    ico-cadena.svg

    Chain

    Sram NX Eagle, 12s, Powerlock

    ico-cambio.svg

    Rear derrailleur

    Sram X01 Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

    ico-mandos.svg

    Shift levers

    Sram Trigger GX Eagle, 12s, X-Actuation 1:1, single click

    ico-pinyon.svg

    Casette

    Sram XG-1275, 10-52T, 12s

    ico-patilla-cambio.svg

    Derailleur hanger

    SRAM UDH

    ico-otros.svg

    Others

    Only available in Europe

    ico-peso.svg

    Weight

    23,2 kg

    ico-display.svg

    Display

    Bosch Kiox 300 / Bosch Mini Remote / Bosch System Controller

    ico-motor.svg

    Motor

    Bosch Performance Line CX-Race (25Km/h), Smart System

    ico-bateria.svg

    Battery

    Bosch Powertube 750Wh
